860SJ
Telescopic Boom LiftElevate your work performance with the JLG 860SJ. Designed for efficiency, this boom lift reaches full elevation in less than 70 seconds.
Imperial
Metric
Key Specifications
- Horizontal Outreach: 75 ft 0 in
- Max Platform Capacity: 750 lb
- Max Platform Height: 86 ft 0 in
Contact Us
Product Details
Elevate your work performance with the JLG 860SJ. Designed for efficiency, this boom lift reaches full elevation in less than 70 seconds.
It's also equipped with a fuel-efficient Tier 4 engine and Advanced Design Electronics System that reduces your cost by increasing fuel efficiency and lowering emissions.
| Axle Oscillation | 200 mm |
|---|---|
| Gradeability | 45% |
| Max Platform Capacity | 340 kg |
| Swing | 360° |
| Tailswing | 1,42 m |
|---|
| Horizontal Outreach | 22.86 m |
|---|---|
| Max Platform Height | 26.21 m |
| Max Working Outreach | 23.51 m |
